Benefits of Voice Connect’s Dark Fibre
Almost unlimited bandwidth
Can carry virtually unlimited bandwidth, limited only by the equipment installed on each end of the service.
ISO 9001 Certified
Voice Connect operates an ISO 9001:2008 certified management system that assures the quality of installation, management and maintenance.
Complete control of your WAN
Complete bandwidth and network protocol flexibility – upgrade by changing your hardware and upstream configuration.
With Voice Connect’s Dark Fibre, you can:
Specifications
Fibre Type | Single Mode Optical Fibre (SMOF) conforming to G.652 spec |
Acrylate Coating Diameter | 245 |
Cladding Diameter | 125.0 ± 0.7 μm |
Cladding Non-Circularity | ≤ 0.7% |
Core/Cladding Concentricity Error | ≤ 0.5 μm |
Attenuation at 1310 nm | 0.4dB/km maximum |
Attenuation at 1550 nm | 0.3dB/km maximum |
Mode Field Diameter at 1310 nm | 9.0 ± 0.4 μm |
Cabled Cut-Off Wavelength | ≤ 1260 nm |
Minimum Zero Dispersion Wavelength | 1302 nm |
Maximum Zero Dispersion Wavelength | 1322 nm |
Dispersion Slope (Maximum at λ0) | 0.092 ps/(nm2.km) |
Dispersion Window 1285 – 1330 nm | ≤ 3.5 ps/km.nm |
Maximum Dispersion at 1550 nm | ≤ 18 ps/km.nm |
Proof Test Strain | 1.0% |
How it works
